Product Details
Absolute luminous flux (lm)
889 - 1410 lm
Power (W)
9 - 13W
Optic options
30°
CRI
80+
CCT
3000K / 4000K
Colour deviation
3 SDCM / 4 SDCM
Dimming methods
Non Dim / Trailing Edge / DALI
Lumen maintenance (hours)
L90B10 > 90,000 hours
Driver
Remote
Input voltage
240v
Housing material
Aluminium
Optic material
PMMA Clear Lens
IP rating
IP65
Warranty
5 years
Country of origin
Australia
Cut out size
Ø75mm
Configurator
How to specify
Select from the available options to configure luminaire
1002.___.___.___.___.___
Project name:
Type number:
Quantity:
Date:
Output
350
9W
889 - 952 lm
500
13W
1315 - 1410 lm
Optic
30 30°
CRI CCT
83 80+ 3000K
84 80+ 4000K
Dimming
61 Non Dim
63 Trailing Edge
66 DALI
Housing colour
W White
Colour Options
Housing colour
White
W
Technical Specifications
Dimensions
