SML330
SML330
Product Details
Absolute luminous flux (lm)
1276 - 2789 lm
Power (W)
14 - 27W
CRI
80+
CCT
3000K / 4000K
Colour deviation
3 SDCM / 4 SDCM
Dimming methods
Non Dim / Trailing Edge / DALI
Lumen maintenance (hours)
L80B10 > 72,000 hours
Driver
Integral
Input voltage
240v
Housing material
Aluminium
Optic material
Opal Polycarbonate
Warranty
7 years
Country of origin
Australia
Configurator
How to specify
Select from the available options to configure luminaire
SML330.___.___.___.___
Project name:
Type number:
Quantity:
Date:
Output
14
14W
1276 - 1404 lm
20
20W
1830 - 2012 lm
27
27W
2535 - 2789 lm
CRI CCT
83 80+ 3000K
84 80+ 4000K
Dimming
61 Non Dim
63 Trailing Edge
66 DALI
Housing colour
W White
B Black
X Custom
Colour Options
Housing colour
Black
B
White
W
Custom
X
Technical Specifications
Dimensions
