VERSALINE 1178 Dual Optic
VL27-1200
Product Details
Absolute luminous flux (lm)
2642 - 4546 lm
Power (W)
27 - 49W
Optic options
58° / U Diffuser
CRI
90+
CCT
2700K / 3000K / 3500K / 4000K / 2700K - 6000K
Colour deviation
3 SDCM
Dimming methods
Non Dim / DALI / Bluetooth (Casambi)
Lumen maintenance (hours)
L80B10 > 60,000 hours
Driver
Remote
Input voltage
240v
Housing material
Aluminium
Optic material
PMMA Clear Lens / Polycarbonate Louvre
Warranty
7 years
Country of origin
Australia
Configurator
How to specify
Select from the available options to configure luminaire
VL27.1200.___.___.___.___.___.___
Project name:
Type number:
Quantity:
Date:
Output
600
27W
2642 - 3140 lm
800
37W
3444 - 4296 lm
1000
44 - 49W
4128 - 4546 lm
Optic
58 58°
U U Diffuser
CRI CCT
927 90+ 2700K
93 90+ 3000K
935 90+ 3500K
94 90+ 4000K
TW 90+ 2700K - 6000K
Dimming
61 Non Dim
66 DALI
68 Bluetooth (Casambi)
Housing colour
W White
B Black
X Custom
Options
W White Louvre
B Black Louvre
Colour Options
Housing colour
Black
B
White
W
Custom
X
Options
White Louvre
W
Black Louvre
B
Technical Specifications
Dimensions
