Overview

Product Description

Flex by name and Flex by design. The Fuji Flex Range re imagines the concept of acoustic ceiling systems through incorporating high quality luminaires.

Beautifully designed and made in Australia the Fuji Flex system allows for the ultimate in lighting customisation while combining acoustic properties to assist in unwanted sound reverberation over workstations and task based areas.

Presenting a sleek minimalist style, the Fuji Juni Flex features lens based optics that ensure exceptional distributions and glare control, a cornerstone of ELS’s design philosophy.

Available with variable output technology to optimise performance to exact project requirements The Fuji Juni Flex can be mounted singularly or as a large group, either with suspended or surface mounted 3 circuit track.

Product Details

Absolute luminous flux up to 2 X 1360 lm
System watts2 X 8W / 2 X 10W / 2 X 12W / 2 X 14W / 2 X 16W
Luminaire efficacyup to 92lm/W
Colour deviation2 SDCM
Colour rendition Index>95
Correlated colour temperature2700K / 3000K / 3500K / 4000K
Lumen maintenanceL90B10 72,000hours
Dimming methodDALI / Casambi
Compatible trackCompatible with Global 3-circuit track
OpticPMMA Clear Lens
Beam angle16° / 24° / 33° / 55° /80°
Luminaire housingAluminium
Luminaire housing colourBlack / White / Custom
Luminaire baffle colourBlack
Custom body finishesCustom powdercoat colour
Acoustic coverPET, 60% post consumer recycled PET
Acoustic cover colourBlack/Black, Black/Cream, Cream/Cream
Warranty7 years
Country of origin Australia

Optional Accessories

Blanking plates are used in place of luminaires when a luminaire is not required

Fuji Blanking Cover White
BLANKING COVER WH
FUJI.BLANK.WH
Fuji Blanking Cover Black
BLANKING COVER BL
FUJI.BLANK.BL

Panel Colour Options

Fuji Panel Cover Options : Black Upper / Cream Lower
BLACK UPPER /
CREAM LOWER
Fuji Panel Cover Options : Black Upper / Black Lower
BLACK UPPER /
BLACK LOWER
Fuji Panel Cover Options : Cream Upper / Cream Lower
CREAM UPPER /
CREAM LOWER

TECHNICAL SPECIFICATIONS

Dimensions

Complete with 3-circuit track adaptor – Track and track accessories sold separately

Fuji hood sound absorption

Fuji Hood dimenions mm
(+ / — 3mm)
o.d.s*mm
(+ / — 3mm)
Performance indicies
awClassSAANRC
JUNI 560mm x 1160mm x 90mm1990.8B0.760.8

*o.d.s = overall depth of system

Fuji hood fire test

BS EN 13501.1: Classification B – s1, d0
ISO 9705: Group 2
GB 8624 B1
ASTM E84 Unadhered: Class 1 or A

Fuji hood emissions

FUJI ROKU, JUNI, KU and HACHI achieves:
ASTM D5116: TVOC Emissions Rate: <0.046mg/m²/hr (7 days)
CDPH Standard Method v1.2: TVOC Emissions Rate: <0.020mg/m³
Formaldehyde Emissions Rate: <1?g/m³

Fuji hood composition

Fuji Hood: 100% PET (64% post-consumer recycled)

Product Variants
HOW TO SPECIFY

FIXED CCT
Select from the available options to configure luminaire

Lumen outputs listed based per luminaire, 2 luminaires supplied per hood package.
Lumen outputs listed based on 4000K, 54degree option in cream cover.

For more details, download the FUJI JUNI FLEX | CEILING SYSTEM Information Sheet

Download the IES files for FUJI JUNI FLEX | CEILING SYSTEM
