Overview
Product Description
Flex by name and Flex by design. The Fuji Flex Range re imagines the concept of acoustic ceiling systems through incorporating high quality luminaires.
Beautifully designed and made in Australia the Fuji Flex system allows for the ultimate in lighting customisation while combining acoustic properties to assist in unwanted sound reverberation.
Presenting a sleek minimalist style, the Fuji Roku Flex features lens based optics that ensure exceptional distributions and glare control, a cornerstone of ELS’s design philosophy.
Available with variable output technology to optimise performance to exact project requirements The Fuji Roku Flex can be mounted singularly or as a large group, either with suspended or surface mounted 3 circuit track.
Product Details
| Absolute luminous flux | up to 1360 lm |
| System watts | 8W / 10W /12W/ 14W / 16W |
| Luminaire efficacy | up to 92lm/W |
| Colour deviation | 2 SDCM |
| Colour rendition Index | >95 |
| Correlated colour temperature | 2700K / 3000K / 3500K / 4000K |
| Lumen maintenance | L90B10 90,000hours |
| Dimming method | DALI / Casambi |
| Compatible track | Compatible with Global 3-circuit track |
| Optic | PMMA Clear Lens |
| Beam angle | 16° / 24° / 33° / 55° / 80° |
| Luminaire housing | Aluminium |
| Luminaire housing colour | Black / White / Custom |
| Luminaire baffle colour | Black |
| Custom body finishes | Custom powdercoat colour |
| Acoustic cover | PET, 60% post consumer recycled PET |
| Acoustic cover colour | Black/Black, Black/Cream, Cream/Cream |
| Warranty | 7 years |
| Country of origin | Australia |
Optional Accessories
Blanking plates are used in place of luminaires when a luminaire is not required
FFL70.HONEYCOMB
FFL70.COLOUR.XXX
FUJI.BLANK.WH
FUJI.BLANK.BL
Panel Colour Options
CREAM LOWER
BLACK LOWER
CREAM LOWER
TECHNICAL SPECIFICATIONS
Dimensions
Complete with 3-circuit track adaptor – Track and track accessories sold separately
Fuji hood sound absorption
| Fuji Hood dimenions mm (+ / — 3mm) | o.d.s*mm (+ / — 3mm) | Performance indicies | |||
| aw | Class | SAA | NRC | ||
| ROKU 560mm x 560mm x 90mm | 199 | 0.75 | C | 0.72 | 0.7 |
*o.d.s = overall depth of system
Fuji hood fire test
BS EN 13501.1: Classification B – s1, d0
ISO 9705: Group 2
GB 8624 B1
ASTM E84 Unadhered: Class 1 or A
Fuji hood emissions
FUJI ROKU, JUNI, KU and HACHI achieves:
ASTM D5116: TVOC Emissions Rate: <0.046mg/m²/hr (7 days)
CDPH Standard Method v1.2: TVOC Emissions Rate: <0.020mg/m³
Formaldehyde Emissions Rate: <1?g/m³
Fuji hood composition
Fuji Hood: 100% PET (64% post-consumer recycled)
Product Variants
HOW TO SPECIFY
FIXED CCT
Select from the available options to configure luminaire
Lumen outputs listed based on 4000K, 54degree option in cream cover.
For more details, download the FUJI ROKU FLEX | CEILING SYSTEM Information Sheet
