Overview
Product Details
- XICATO XTM technology
- Wall wash reflector
- Die cast aluminium trim, powdercoated white
- Frost glass internal lens
- 3000K, 4000K or 2700K upon request
- Standard CRI 83+ or Artist CRI 98
- Excellent colour consistency from luminaire to luminaire
- 5 year colour consistency warranty – no colour shift
- L70B0 @ 55,000 hours
- Available in a Bluetooth dimmable version refer to Smart Lighting Catalogue
Spacing Calculations
x = 1/3 h
y = x
eg.3m high ceiling – x=1m, y=1m
Colour Finish
- white WH
Codes & Downloads
XTM 240V – 83+ CRI
| Non Dimmable | DALI Dimmable | CCT | Lumens | Watts |
|---|---|---|---|---|
| WW135.XTM7.8030.61 | WW135.XTM7.8030.66 | 3000K | 789 | 12 |
| WW135.XTM7.8040.61 | WW135.XTM7.8040.66 | 4000K | 789 | 12 |
XTM 240V – 98 CRI
| Non Dimmable | DALI Dimmable | CCT | Lumens | Watts |
|---|---|---|---|---|
| WW135.XTM7.9530.61 | WW135.XTM7.9530.66 | 3000K | 789 | 19.5 |
| WW135.XTM7.9540.61 | WW135.XTM7.9540.66 | 4000K | 789 | 19.5 |
For more details, download the WALL WASH 135 DOWNLIGHT Information Sheet
