Overview
Product Description
Flex by name and Flex by design. The Flex Fixed 50 luminiare is the most versatile high performance spotlight luminaire available in the ELS range.
Presenting a sleek minimalist style, the Flex Fixed 50 features optics that ensure exceptional glare control a cornerstone of ELS’s design philosophy.
It is available with variable output technology to optimise performance to exact project requirements.
Product Details
| Absolute luminous flux | 487lm – 1243lm |
| System watts | 6W / 8W / 10W / 12W / 14W |
| Luminaire efficacy | up to 96lm/W |
| Colour deviation | 2 SDCM |
| Colour rendition Index | >95 |
| Correlated colour temperature | 3000K / 4000K |
| Lumen maintenance | L90B10 90,000hours |
| Optic | PMMA Clear Lens |
| Beam angle | 16° / 24° / 33° / 55° / 40°x59° |
| Dimming method | Trailing Edge / DALI / Casambi |
| Luminaire housing | Aluminium |
| Luminaire baffle colour | Black |
| Luminaire housing colour | Black / White / Silver / Custom |
| Custom body finishes | Custom powdercoat colour |
| Country of origin | Australia |
Codes & Downloads
| Non Dimmable | TRAILING EDGE DIMMABLE | DALI Dimmable | Casambi Dimmable | Beam Angle | CCT | Lumens | Watts |
|---|---|---|---|---|---|---|---|
| FFL50.150.16.93.61 | FFL50.150.16.93.63 | FFL50.150.16.93.66 | FFL50.150.16.93.68 | 16° | 3000K | 520 | 6 |
| FFL50.150.16.94.61 | FFL50.150.16.94.63 | FFL50.150.16.94.66 | FFL50.150.16.94.68 | 16° | 4000K | 568 | 6 |
| FFL50.150.24.93.61 | FFL50.150.24.93.63 | FFL50.150.24.93.66 | FFL50.150.24.93.68 | 24° | 3000K | 530 | 6 |
| FFL50.150.24.94.61 | FFL50.150.24.94.63 | FFL50.150.24.94.66 | FFL50.150.24.94.68 | 24° | 4000K | 578 | 6 |
| FFL50.150.33.93.61 | FFL50.150.33.93.63 | FFL50.150.33.93.66 | FFL50.150.33.93.68 | 33° | 3000K | 531 | 6 |
| FFL50.150.33.94.61 | FFL50.150.33.94.63 | FFL50.150.33.94.66 | FFL50.150.33.94.68 | 33° | 4000K | 579 | 6 |
| FFL50.150.55.93.61 | FFL50.150.55.93.63 | FFL50.150.55.93.66 | FFL50.150.55.93.68 | 55° | 3000K | 493 | 6 |
| FFL50.150.55.94.61 | FFL50.150.55.94.63 | FFL50.150.55.94.66 | FFL50.150.55.94.68 | 55° | 4000K | 538 | 6 |
| FFL50.150.OV.93.61 | FFL50.150.OV.93.63 | FFL50.150.OV.93.66 | FFL50.150.OV.93.68 | 49° x 59° | 3000K | 487 | 6 |
| FFL50.150.OV.94.61 | FFL50.150.OV.94.63 | FFL50.150.OV.94.66 | FFL50.150.OV.94.68 | 49° x 59° | 4000K | 531 | 6 |
| Non Dimmable | TRAILING EDGE DIMMABLE | DALI Dimmable | Casambi Dimmable | Beam Angle | CCT | Lumens | Watts |
|---|---|---|---|---|---|---|---|
| FFL50.200.16.93.61 | FFL50.200.16.93.63 | FFL50.200.16.93.66 | FFL50.200.16.93.68 | 16° | 3000K | 678 | 8 |
| FFL50.200.16.94.61 | FFL50.200.16.94.63 | FFL50.200.16.94.66 | FFL50.200.16.94.68 | 16° | 4000K | 741 | 8 |
| FFL50.200.24.93.61 | FFL50.200.24.93.63 | FFL50.200.24.93.66 | FFL50.200.24.93.68 | 24° | 3000K | 690 | 8 |
| FFL50.200.24.94.61 | FFL50.200.24.94.63 | FFL50.200.24.94.66 | FFL50.200.24.94.68 | 24° | 4000K | 755 | 8 |
| FFL50.200.33.93.61 | FFL50.200.33.93.63 | FFL50.200.33.93.66 | FFL50.200.33.93.68 | 33° | 3000K | 690 | 8 |
| FFL50.200.33.94.61 | FFL50.200.33.94.63 | FFL50.200.33.94.66 | FFL50.200.33.94.68 | 33° | 4000K | 756 | 8 |
| FFL50.200.55.93.61 | FFL50.200.55.93.63 | FFL50.200.55.93.66 | FFL50.200.55.93.68 | 55° | 3000K | 643 | 8 |
| FFL50.200.55.94.61 | FFL50.200.55.94.63 | FFL50.200.55.94.66 | FFL50.200.55.94.68 | 55° | 4000K | 703 | 8 |
| FFL50.200.OV.93.61 | FFL50.200.OV.93.63 | FFL50.200.OV.93.66 | FFL50.200.OV.93.68 | 49° x 59° | 3000K | 634 | 8 |
| FFL50.200.OV.94.61 | FFL50.200.OV.94.63 | FFL50.200.OV.94.66 | FFL50.200.OV.94.68 | 49° x 59° | 4000K | 693 | 8 |
| Non Dimmable | TRAILING EDGE DIMMABLE | DALI Dimmable | Casambi Dimmable | Beam Angle | CCT | Lumens | Watts |
|---|---|---|---|---|---|---|---|
| FFL50.250.16.93.61 | FFL50.250.16.93.63 | FFL50.250.16.93.66 | FFL50.250.16.93.68 | 16° | 3000K | 828 | 10 |
| FFL50.250.16.94.61 | FFL50.250.16.94.63 | FFL50.250.16.94.66 | FFL50.250.16.94.68 | 16° | 4000K | 907 | 10 |
| FFL50.250.24.93.61 | FFL50.250.24.93.63 | FFL50.250.24.93.66 | FFL50.250.24.93.68 | 24° | 3000K | 843 | 10 |
| FFL50.250.24.94.61 | FFL50.250.24.94.63 | FFL50.250.24.94.66 | FFL50.250.24.94.68 | 24° | 4000K | 923 | 10 |
| FFL50.250.33.93.61 | FFL50.250.33.93.63 | FFL50.250.33.93.66 | FFL50.250.33.93.68 | 33° | 3000K | 845 | 10 |
| FFL50.250.33.94.61 | FFL50.250.33.94.63 | FFL50.250.33.94.66 | FFL50.250.33.94.68 | 33° | 4000K | 925 | 10 |
| FFL50.250.55.93.61 | FFL50.250.55.93.63 | FFL50.250.55.93.66 | FFL50.250.55.93.68 | 55° | 3000K | 785 | 10 |
| FFL50.250.55.94.61 | FFL50.250.55.94.63 | FFL50.250.55.94.66 | FFL50.250.55.94.68 | 55° | 4000K | 860 | 10 |
| FFL50.250.OV.93.61 | FFL50.250.OV.93.63 | FFL50.250.OV.93.66 | FFL50.250.OV.93.68 | 49° x 59° | 3000K | 774 | 10 |
| FFL50.250.OV.94.61 | FFL50.250.OV.94.63 | FFL50.250.OV.94.66 | FFL50.250.OV.94.68 | 49° x 59° | 4000K | 848 | 10 |
| Non Dimmable | TRAILING EDGE DIMMABLE | DALI Dimmable | Casambi Dimmable | Beam Angle | CCT | Lumens | Watts |
|---|---|---|---|---|---|---|---|
| FFL50.300.16.93.61 | FFL50.300.16.93.63 | FFL50.300.16.93.66 | FFL50.300.16.93.68 | 16° | 3000K | 974 | 12 |
| FFL50.300.16.94.61 | FFL50.300.16.94.63 | FFL50.300.16.94.66 | FFL50.300.16.94.68 | 16° | 4000K | 1065 | 12 |
| FFL50.300.24.93.61 | FFL50.300.24.93.63 | FFL50.300.24.93.66 | FFL50.300.24.93.68 | 24° | 3000K | 992 | 12 |
| FFL50.300.24.94.61 | FFL50.300.24.94.63 | FFL50.300.24.94.66 | FFL50.300.24.94.68 | 24° | 4000K | 1084 | 12 |
| FFL50.300.33.93.61 | FFL50.300.33.93.63 | FFL50.300.33.93.66 | FFL50.300.33.93.68 | 33° | 3000K | 994 | 12 |
| FFL50.300.33.94.61 | FFL50.300.33.94.63 | FFL50.300.33.94.66 | FFL50.300.33.94.68 | 33° | 4000K | 1086 | 12 |
| FFL50.300.55.93.61 | FFL50.300.55.93.63 | FFL50.300.55.93.66 | FFL50.300.55.93.68 | 55° | 3000K | 923 | 12 |
| FFL50.300.55.94.61 | FFL50.300.55.94.63 | FFL50.300.55.94.66 | FFL50.300.55.94.68 | 55° | 4000K | 1009 | 12 |
| FFL50.300.OV.93.61 | FFL50.300.OV.93.63 | FFL50.300.OV.93.66 | FFL50.300.OV.93.68 | 49° x 59° | 3000K | 893 | 12 |
| FFL50.300.OV.94.61 | FFL50.300.OV.94.63 | FFL50.300.OV.94.66 | FFL50.300.OV.94.68 | 49° x 59° | 4000K | 976 | 12 |
| Non Dimmable | TRAILING EDGE DIMMABLE | DALI Dimmable | Casambi Dimmable | Beam Angle | CCT | Lumens | Watts |
|---|---|---|---|---|---|---|---|
| FFL50.350.16.93.61 | FFL50.350.16.93.63 | FFL50.350.16.93.66 | FFL50.350.16.93.68 | 16° | 3000K | 1114 | 14 |
| FFL50.350.16.94.61 | FFL50.350.16.94.63 | FFL50.350.16.94.66 | FFL50.350.16.94.68 | 16° | 4000K | 1218 | 14 |
| FFL50.350.24.93.61 | FFL50.350.24.93.63 | FFL50.350.24.93.66 | FFL50.350.24.93.68 | 24° | 3000K | 1099 | 14 |
| FFL50.350.24.94.61 | FFL50.350.24.94.63 | FFL50.350.24.94.66 | FFL50.350.24.94.68 | 24° | 4000K | 1240 | 14 |
| FFL50.350.33.93.61 | FFL50.350.33.93.63 | FFL50.350.33.93.66 | FFL50.350.33.93.68 | 33° | 3000K | 1166 | 14 |
| FFL50.350.33.94.61 | FFL50.350.33.94.63 | FFL50.350.33.94.66 | FFL50.350.33.94.68 | 33° | 4000K | 1243 | 14 |
| FFL50.350.55.93.61 | FFL50.350.55.93.63 | FFL50.350.55.93.66 | FFL50.350.55.93.68 | 55° | 3000K | 1071 | 14 |
| FFL50.350.55.94.61 | FFL50.350.55.94.63 | FFL50.350.55.94.66 | FFL50.350.55.94.68 | 55° | 4000K | 1155 | 14 |
| FFL50.350.OV.93.61 | FFL50.350.OV.93.63 | FFL50.350.OV.93.66 | FFL50.350.OV.93.68 | 49° x 59° | 3000K | 1023 | 14 |
| FFL50.350.OV.94.61 | FFL50.350.OV.94.63 | FFL50.350.OV.94.66 | FFL50.350.OV.94.68 | 49° x 59° | 4000K | 1117 | 14 |
For more details, download the LEX FIXED 50 | LENS Information Sheet
