Product Details
- 95+ CRI
- 3000K or 4000K
- Painted white reflector
- Thin trim for a “trimless” look
- Rebated frost glass lens
- L90B10 up to 90,000 hours
- 2 X SDCM
- IP44 version
Codes & Downloads
TRIMLESS 90 Gen2 – 250mA
| Non Dimmable |
Trailing Edge Dimmable |
DALI Dimmable |
Beam |
CCT |
Lumens |
Watts |
| LX90.250.93.61.TL |
LX90.250.93.63.TL |
LX90.250.93.66.TL |
46° |
3000K |
651 |
10 |
| LX90.250.94.61.TL |
LX90.250.94.63.TL |
LX90.250.94.66.TL |
46° |
4000K |
702 |
10 |
TRIMLESS 90 Gen2 – 350mA
| Non Dimmable |
Trailing Edge Dimmable |
DALI Dimmable |
Beam |
CCT |
Lumens |
Watts |
| LX90.350.93.61.TL |
LX90.350.93.63.TL |
LX90.350.93.66.TL |
46° |
3000K |
885 |
14 |
| LX90.350.94.61.TL |
LX90.350.94.63.TL |
LX90.350.94.66.TL |
46° |
4000K |
971 |
14 |
For more details, download the 90 TRIMLESS GEN2 Information Sheet
Download the IES file for the TRIMLESS 90 GEN2
