Overview

Product Description

Designed and made in Australia the Valley 78 Advanced is a completely customisable and versatile linear lighting solution.

Quality of light is key to the design of the luminaires with the option to specify a specifically engineered ‘Full Spectrum’ version designed to minimise potential negative effects of artificial lighting to people, pets and plants.

Product Details

Absolute luminous flux p/m1502lm – 2002lm
System watts p/m29W / 40W
Colour deviation2 SDCM
Colour rendition Index>95
Correlated colour temperatureStatic White – 3000K / 4000K, Full Spectrum – 4000K
Cyanosis approvalAvailable with CRI 4000K
Dimming methodNon dimm / DALI / Casambi
DriverIntegral
MaterialExtruded aluminium body, polycarbonate diffuser
IlluminationDirect or direct / indirect
OpticOpal flat diffuser
MountingSuspended
AccessoriesEnd caps / joiners / coverplate
Housing colourBlack / White / Custom
LengthCustom lengths made to order
Warranty10 years
Colour consistency warranty10 years
Country of originAustralia

Custom Luminaire Modifications

  • 2700K & 3500K
  • Screwless endcaps

How to Order

Codes & Downloads

STATIC WHITE

Direct Illumination Flat DiffuserDelivered Lumens per 1000mmSystem Watts per meterCRILED’s divisible by
13491395+25mm

STATIC WHITE – UPWARD ILLUMINATION

Indirect IlluminationDelivered Lumens per 1000mmSystem Watts per meterCRILED’s divisible by
226495+25mm
6531390+25mm

FULL SPECTRUM

Direct Illumination Flat DiffuserDelivered Lumens per 1000mmSystem Watts per meterCRILED’s divisible by
10402595+50mm

FULL SPECTRUM – UPWARD ILLUMINATION

Indirect IlluminationDelivered Lumens per 1000mmSystem Watts per meterCRILED’s divisible by
5561395+50mm

For more details, download the UD50 ADVANCED Information Sheet

IES file coming soon
