Overview

SYSTEMKANAL 66

Product Description

Designed and made in Australia the SK 66 recessed is a completely customisable and versatile linear lighting solution. The magic of this luminaire is that it presents beautifully and performs brilliantly without imposing on the overall design aesthetic.

This amazing luminaire also features the option of a specifically engineered U diffuser to optimise vertical illuminance. Available with Variable Output Technology the SK 66 recessed ensures complete lighting control and performance for the user.

Product Details

Absolute luminous flux p/m827lm – 3510lm
System watts p/m9W /12W / 17W / 21W / 26W / 30W
Colour deviation3 SDCM
Colour rendition Index>80 / >90
Correlated colour temperature3000K / 4000K
Cyanosis approvalAvailable with 90+CRI 4000K
Lumen maintenanceL80B10 up to 72,000hours
Dimming methodNon dimm / DALI / Casambi
DriverIntegral
MaterialExtruded aluminium body, polycarbonate diffuser
IlluminationDirect
OpticOpal flat diffuser / opal U diffuser
MountingRecessed
AccessoriesEnd caps / joiners / mitered corners / coverplate
Housing colourBlack / White / Custom
LengthCustom lengths made to order
Warranty7 years
Country of originAustralia

Custom Luminaire Modifications

  • 2700K & 3500K
  • White tunable 2700K-6500K
  • RGBW
  • IP54
  • Screwless endcaps
  • Integrated track spots
  • Integrated pendant luminaires

How to Order

Codes & Downloads

80+ CRI – FLAT DIFFUSER

Direct IlluminationDelivered Lumens per 980mmSystem Watts per meterCRILED’s divisible by
942980+140mm
13001280+140mm
18191780+140mm
21642180+140mm
26872680+140mm
29753080+140mm

90+ CRI – FLAT DIFFUSER

Direct IlluminationDelivered Lumens per 980mmSystem Watts per meterCRILED’s divisible by
827990+140mm
11411290+140mm
15911790+140mm
18962190+140mm
23552690+140mm
26053090+140mm

80+ CRI – U DIFFUSER

Direct IlluminationDelivered Lumens per 980mmSystem Watts per meterCRILED’s divisible by
1112980+140mm
15341280+140mm
21461780+140mm
25532180+140mm
31702680+140mm
35103080+140mm

90+ CRI – U DIFFUSER

Direct IlluminationDelivered Lumens per 980mmSystem Watts per meterCRILED’s divisible by
937990+140mm
12921290+140mm
18011790+140mm
21462190+140mm
26662690+140mm
29493090+140mm

For more details, download the SYSTEM 66 Information Sheet

Download the IES files for SYSTEM 66
