Overview



Product Details

  • 85+ CRI
  • Over 100 Lm/w
  • 3000K, 4000K or 2700K upon request
  • High quality, mirror finish low glare reflector
  • L90B10 up to 90,000 hours
  • Multi directional, pivots on 2 axis with 83° tilt
  • 2 X SDCM
  • 15°, 24°, 36°, 60°

Colour Finish

  • white WH
  • black BLK

Codes & Downloads

CR155 – 500mA

Non DimmableTrailing Edge DimmableDALI DimmableBeamCCTLumensWatts
CR155.500.15.93.61CR155.500.15.93.63CR155.500.15.93.6615°3000K204619.5
CR155.500.15.94.61CR155.500.15.94.63CR155.500.15.94.6615°4000K208619.5
CR155.500.24.93.61CR155.500.24.93.63CR155.500.24.93.6624°3000K212419.5
CR155.500.24.94.61CR155.500.24.94.63CR155.500.24.94.6624°4000K216619.5
CR155.500.36.93.61CR155.500.36.93.63CR155.500.36.93.6636°3000K212819.5
CR155.500.36.94.61CR155.500.36.94.63CR155.500.36.94.6636°4000K217019.5
CR155.500.60.93.61CR155.500.60.93.63CR155.500.60.93.6660°3000K212819.5
CR155.500.60.94.61CR155.500.60.94.63CR155.500.60.94.6660°4000K217019.5

CR155 – 700mA

Non DimmableTrailing Edge DimmableDALI DimmableBeamCCTLumensWatts
CR155.700.15.93.61CR155.700.15.93.63CR155.700.15.93.6615°3000K274227.5
CR155.700.15.94.61CR155.700.15.94.63CR155.700.15.94.6615°4000K279627.5
CR155.700.24.93.61CR155.700.24.93.63CR155.700.24.93.6624°3000K292527.5
CR155.700.24.94.61CR155.700.24.94.63CR155.700.24.94.6624°4000K298327.5
CR155.700.36.93.61CR155.700.36.93.63CR155.700.36.93.6636°3000K290827.5
CR155.700.36.94.61CR155.700.36.94.63CR155.700.36.94.6636°4000K296627.5
CR155.700.60.93.61CR155.700.60.93.63CR155.700.60.93.6660°3000K290827.5
CR155.700.60.94.61CR155.700.60.94.63CR155.700.60.94.6660°4000K296627.5

For more details, download the CARDO155 DOWNLIGHT Information Sheet
